Product Details:
|
| Foldable: | NO | Size: | BMX 700C ROAD, 17"/19" (height) Optional |
|---|---|---|---|
| Use: | BMX, Mountain Bikes, Road Bicycles, Dirt Jumper | Weight: | 3.42kg |
| Surface Processing Mode: | Gloss | Type: | Aluminum Alloy Frame |
| Product Name: | Dual Suspension Mountain Bike Frame | Material: | Aluminum Alloy, AL7005 |
| Bottom Bracket: | BB73mm Threaded | Frame Travel: | 120mm |
| Color: | BlackRed / BlackBlue / BlackGray | Applicable Wheel Size: | 27.5"/29" |
| Process: | Smooth Welding, Cable Internal, Bright Painting, UV Laser Decal | Usage: | Mountain Bike |
| Custom: | Available |
Product Name | Full suspension Mountain Bike Frame |
Wheel Size | 27.5+ (apply to 27.5" and 29" wheel) |
Frame size | 17"/ 19" |
Material | Alu alloy AL7005 |
Seat post size | 31.6mm+Clamp 34.9mm |
Head tube size | 44*56mm Tapered |
BB width | BB73mm Threaded |
O.L.D: Quick release | 10*135mm |
Rear shock | DNM-AOY 36RC, 165*35mm(6.50×1.38in) Double chamber, Rebound fine adjustment, Compression locking, Adjustable air chamber preload&Stroke |
Frame travel | 120mm |
Fork travel | 120mm |
Apply to tyre max | 27.5*3.0" or 29*2.35" |
Brake | Disc Brake |
Cable Routing | Internal |
Front deraillure amount | Can not |
Compatible with Fork | Straight or Tapered |
Level | XC, AM |
Process | Hydraulic Forming Pipe , T4/T6, Four-bar linkage, Sealed bearing turning, Smooth welding, Cable internal, Bright painting, UV laser decals |
Weight | Frame≈3.42KG, Rear Shox≈295g |
